EJA110E-JLH4G-722ED Yokogawa EJA Differential Pressure Transmitter

EJA110E-JLH4G-722ED  Yokogawa EJA Differential Pressure Transmitter
EJA110E-JLH4G-722ED  Yokogawa EJA Differential Pressure Transmitter

큰 이미지 :  EJA110E-JLH4G-722ED Yokogawa EJA Differential Pressure Transmitter

제품 상세 정보:
Place of Origin: Japan
브랜드 이름: YOKOGAWA
인증: ROHS
Model Number: EJA110E-JLH4G-722ED/KU22/A/D4
결제 및 배송 조건:
Minimum Order Quantity: 1
가격: negotiable
Packaging Details: carton 40*30*30cm
Delivery Time: on request
Payment Terms: T/T
Supply Ability: 1~1000pcs
상세 제품 설명
필수적 지표: 더 레인지 설정 스위치 (누름 버튼)과 디지털 표시 장치 증폭기 주택: 주조 알루미늄 합금
설치: 수평 배관과 왼쪽 고압 출력 신호: 디지털 통신 (하트 5/HART 7 프로토콜)과 4 내지 20 마 DC
모델: EJA110E-JLH4G-722ED/KU22/A/D4 제조사: YOKOGAWA
제품 유형: EJA110E 차압발진기 선박 무게: 8개 kg

EJA110E-JLH4G-722ED Yokogawa EJA Differential Pressure Transmitter






Description:


Manufacturer : Yokogawa

Product No. : EJA110E-JLH4G-722ED/KU22/A/D4

Product type : EJA110E Differential pressure transmitter

Output signal : J = 4 to 20 mA DC with digital communication (HART 5/HART 7 protocol)

Measurement span (capsule) : L = 0.5 to 10 kPa (2.0 to 40 inH2O) (For Wetted parts material code M, H, T, A, D, B and W)

Wetted parts material : H = ASTM CF-8M Cover flange and process connector, Hastelloy C-276 Capsule, PTFE Teflon Capsule gasket , 316 SST Vent/Drain plug.

Process connections : 4 = with 1/2 NPT female process connector

Bolts and nuts material : G = 316L SST

Installation : 7 = Vertical piping, left side high pressure, and process connection downside

Amplifier housing : 2 = ASTM CF-8M stainless steel

Electrical connection : 2 = 1/2 NPT female, two electrical connections without blind plugs

Integral indicator : E = Digital indicator with the range setting switch (push button)

Mounting bracket : D =304 SST or SCS13A 2-inch pipe mounting, L type (for vertical piping)

ATEX : KU22 = Combined KF22, KS21 and ATEX Intrinsically safe Ex ic *1 *3 [ATEX Intrinsically safe Ex ic] Applicable Standard: EN 60079-0:2012, EN 60079-11:2012 II 3G Ex ic IIC T4 Gc, Amb. Temp.: –30 to 60°C (–22 to 140°F) *2 Ui=30 V, Ci=27.6 nF, Li=0 µH

Lightning protector : A = Transmitter power supply voltage: 10.5 to 32 V DC (10.5 to 30 V DC for intrinsically safe type.) Allowable current: Max. 6000 A (1×40 µs), Repeating 1000 A (1×40 µs) 100 times Applicable Standards: IEC 61000-4-4, IEC 61000-4-5

Calibration units : D4 = M calibration (kgf/cm2 unit)

Weight : 2.8 Kg + 1.5 Kg

Shipping Weight : 8 Kg











Additional Informaiton:



EJA-E series models in their standard configuration, with the exception of the Fieldbus, PROFIBUS and Low Power types, are certified as complying with SIL 2 safety requirements.

Accuracy: ±0.055% of Span
Stability: ±0.1% of URL per 10 years
Response Time: 90 msec

Vent/Drain plug : 316 SST

Process connections : 4 = with 1/2 NPT female process connector

Bolts and nuts materia : G = 316L SST

Installation : 9 = Horizontal piping and left side high pressure

Amplifier housing : 1 = Cast aluminum alloy









Common models for reference:



EJA110E-DMS4G-717DD
EJA110E-DHS4G-717DD
EJA110E-DHS5J-912NB
EJA110E-DMS5J-912NB
EJA110E-DLH5J-912NB
EJA110E-JMS4J-717DD
EJA110E-JMS5J-712ND/D4
EJA110E-JFS4G-917DD/D4
EJA110E-DLH5J-914DB
EJA110E-JMS4G-719DD
EJA110E-DLH4J-812DD/D4
EJA110E-JMS4G-719DD/KS21/D3
EJA110E-DMS4J-912DB-D4
EJA110E-JMS4G-717DD
EJA110E-JHS4G-717DD
EJA110E-JMS4J-912DB/D4
EJA110E-DHS4J-912DB/D4
EJA110E-DHS4J-710DD/D3/C1
EJA110E-DMS4G-717DD
EJA110E-JFS2J-915EB/X2
EJA110E-JMS5G-93DEB
EJA110E-JMS5G-93DEB/K1
EJA110E-JMS4C-93DEB
EJA110E-JFS4C-93DEB
EJA110E-JHS3J-919EB
EJA110E-DFS4G-717ND
EJA110E-DMS4G-717ND
EJA110E-DLH2J-710DD
EJA110E-JFS4G-912DN/KF22/A/D4
EJA110E-JVS4G-917EB/FU1/D3/A
EJA110E-JMS4G-824NJ/KU22
EJA110E-JHS4G-912EJ
EJA110E-JFS4G-912DB/FF1
EJA110E-JMS4G-912DB/FF1/D3
EJA110E-JMS5G-919DB/X2/D4/M01/T12/KU22
EJA110E-FMS5C-92DDN/KS26/D3/M01/T12/N4
EJA110E-JHS5G-92DDJ/KS21/D3/M01/T12/A
EJA110E-JLH5G-92DDJ/KS21/D3/M01/T12/A
EJA110E-JLH5G-92DDJ/KS21/D3/M01/T12/A
EJA110E-FMS5G-919DB/X2/D3/M01/T12
EJA110E-FMS4G-719DD/KS26/D3
EJA110E-JHS5G-919DB/KU22/X2/D3/M01/T12
EJA110E-JLH5G-919NN/KS21/M01/T12
EJA110E-JLH5G-92DDB/KU22/X2/D4/M01/T12
EJA110E-FMS5J-914DB/KS26/D4/M01
EJA110E-FHS4G-919DB/KS26/D4/X2/M11/T12
EJA110E-FHS5G-919DB/KS26/D3/X2/M01/T13/HG
EJA110E-FMS5G-919DB/KS26/D3/X2/M01/T13/HG
EJA110E-JHS5G-919DB/KU22/D4/X2/M01/T12
EJA110E-JHS5G-919DB/KU22/D3/X2/M01/T12
EJA110E-JHS5G-919DB/KU22/D3/X2/M01/T13/HG
EJA110E-JMS5G-919DB/KU22/D3/X2/M01/T13/HG
EJA110E-JMS5G-919DB/X2/D4/M01/T12/KU22
EJA110E-JHS5G-719DD/X2/D3/M01/T12/KU22
EJA110E-JMS5G-719DD/X2/D4/M01/T12/KU22
EJA110E-FMS5G-919DB/KS26/X2/D4/M01/T12
EJA110E-JLH4G-722ED/KU22/A/D4
EJA110E-JHS4G-722ND/KU22/A/D4
EJA110E-FHS5G-919DN/KS26/D3/M01/T12
EJA110E-JLH5G-919DB/KU22/X2/D4/M01/T12
EJA110E-DMS4J-912DN/FS1/M11/T12/D4
EJA110E-JMA5G-92DEJ/SF2/D3/C2/M01/T12
EJA110E-JMS4G-919DB/D3/KS21
EJA110E-JMS5G-917DJ/KF22/D4/X2/C1/M01/T13/HC/HG
